TRACTOR HYDRAULIC POWER-PACK UNIT WITH A CAPACITY OF 100L FLOW 53L/MIN 3XZ80 - WITH OIL COOLER
Description:
The tractor hydraulic unit is a separate unit that allows us to control attachments on tractors that do not generate enough flow or hydraulic power on their own. The RS-25 hydraulic unit generates sufficient flow, enabling versatile use, enough power, and reliability while maintaining power on the tractor. It is used for various applications in viticulture, forestry, agriculture (topping, splitters, snow blowers, loaders, mowers, sweeping machines, spreaders, …)
Possible assembly of units on order with different flows from 33 to 74 l/min, from 1 to 4 hydraulic levers, with or without a cooler.
Max. dimensions of the entire unit: length 50cm, width 90cm, height 110cm.
Oil viscosity 46.
| ASSEMBLY OF THE UNIT ON ORDER | |
| HYDRAULIC VALVE | ITEM CODE |
| Hydraulic valve 1xP80 | 10115 |
| Hydraulic valve 2xP80 | 10116 |
| Hydraulic valve 3xP80 | 10796 |
| Hydraulic valve 4xP80 | 10117 |
| RESERVOIR | ITEM CODE |
| Metal reservoir 75 lit | 12933 |
| Metal reservoir 100 lit | 12934 |
| OIL COOLER | ITEM CODE |
| Oil cooler 20-100 lit (12V) | 10408 |
| Without oil cooler | - |
Possible production of tractor hydraulic unit with different flow rates.
| PUMP | PUMP FLOW | MAX. PTO RPM | FLOW | MAX. PRESSURE | RATED PRESSURE OF THE UNIT |
| [cc] | [rpm] | [l/min] | [bar] | [bar] | |
| Gr.2 | 16 | 540 | 33 | 300 | 250 |
| 20 | 41 | ||||
| 25 | 52 | 250 | 200 | ||
| 28 | 57 | 200 | 160 | ||
| 30 | 62 | ||||
| Gr.3 | 32 | 66 | 250 | 200 | |
| 36 | 74 |
